Basic Truck Includes

• 140 Gallon all welded bolt-on fuel tank
• Engine Equipped Fuel / Water Separator
• Donaldson dry-type Air Cleaner w/Safety Element & Restriction Indicator and vertical air intake extension
• Muffler w/Stack Guard
• 24-Volt Electrical System, 110 amp alternator
• Taylor Integrated Control System (TICS) with CANbus Technology with Diagnostics, through dash mounted 7-in. diagonal full color touch screen display, Seat Belt Sequence Neutral Lock, Customer Ability to turn Accessory Functions On/Off, Power on Demand, Idle and Neutral Shutdown
• Dual USB port in cab
• Two Heavy-duty Batteries (2-8DA) with battery disconnect switch
• LED work lights total 8, 2 at front on each side of cab, total 4, 2 mounted on "A" frame or back of cab depending on model, 2 front on mast, one low and one high
• Lighted Instruments
• Remote mounted hour meter
• Tilt Steering Wheel
• Electric Horn 118 DBA
• Anti-restart Ignition Switch
• Keyswitch-actuated Amber Strobe Light
• Reverse-actuated Backup Alarm
• Forward actuated forward alarm
• Rear View Convex Mirrors
• Powershift Transmission - 4 speed w/Declutch, Modulated, Fully Electronic, Electric Shift Control, separate air/oil cooling and APC-200 automatic powershift control, with direction controls on push buttons on joystick
• Taylor Wide-stance Steer Axle with stud protectors
• Planetary Drive Axle, Bolt-on
• Wet Disc hydraulic-actuated brakes with air to air cooler for brake or and hydraulic oil
• Air cooled remote mounted hydraulic oil cooler and Engine Fuel Cooler (Fuel Cooler not required on Volvo Engines)
• Auxiliary Drive Line Mounted Parking Brake
• Hydrostatic Power Steering
• 2 Section Hydraulic Valve, lift and tilt
• Bolt on 150 gallon hydraulic oil tank
• All welded chassis, lift eyes, 2 mast mounted, 2 chassis mounted, not level pick
• Electric Joystick Operated Controls and Switch Controls, with direction controls on push buttons on joystick
• Elevated Center Mount Operator and ANSI B56.1 FOPS Overhead Guard/Cab, 2-door, includes one 32,000 BTU heater, one circulation fan, front and rear windshield wipers with control switches, front windshield washer, dome light, all tinted glass door hold back latches with trip buttons, with grey insulation and removable black floor mats
• Adjustable black vinyl covered air ride suspension seat w/Flip-down, adjustable-angle Arm Rests, Orange Seat Belt and OPS Switch, Seat has left 15/right 20 degree rotation
• Cab color black only
• Full flow wire Mesh Strainers and Return Line Filters w/Replaceable Elements in hydraulic Tank
• Parker hydraulic gear type pumps, fittings, hoses
• Accumulator in Lift Circuit
• Removeable counterweight truck
• 40,000 pound removable counterweight, 90,000lbs vehicle transport weight with counterweight when equipped with C pin type 120-in. side shift carriage and pin type coil ram, 15-in. OD X 96-in. long X 25-in. top of ram to ground
