Standard Features: X-550RC

• 10-ft ULTRA-VU 2-Stage Mast (142-in lowered height)
• 100-in “C” Carriage
• 5-in X 10-in X 72-in pin mounted Forks
• Cummins QSB 6.7L 225Hp Tier-4 Final diesel Engine
• Donaldson dry-type air cleaner w/safety element & restriction indicator (vertical airintake)
• Dana TC-32 3-Speed powershift Transmission
• Powertrain Protection System for engine and transmission
• Axeltech PRLC-1794W HD planetary Drive Axle with Wet Disc Brakes
• Taylor 450 welded steel Steer Axle (single hydraulic cylinder design with heavy-dutylinks from the cylinder ram directly to tapered roller bearing mounted spindles)
• 14.00 X 25 – 20PR bias pneumatic drive and steer tires

Chassis

• All-welded steel frame with 4 Lifting Eyes
• Removable counterweight (30,000-lbs)
• Replaceable bolt-on steps and handrails
• Lockable Fuel Cap
• Sliding engine hood (on rollers), side service doors and removable floor panels opento expose drive train for ease of maintenance.

Cab

• Enclosed 2-door steel all-welded tilting cab (includes dome light, wide angle mirrors,door hold back latches with trip handles, handrails, black floor mats and is isolationmounted for noise and vibration reduction)
• 32,000 BTU heater and interior circulation fan
• Tinted glass with front and rear windshield wipers and front windshield washer
• Fully adjustable air ride swivel seat with 35° of rotation (15°/20° left-right)
• Multifunction Joystick mounted on adjustable arm rest (11-button command withintegrated directional shift control)
• Operator Restraint System (Orange, anti-cinch seat belt with starting sequenceneutral lock)
• Operator Presence System with timed idle and neutral shutdown(5 minute default,password adjustable from 1-120 minutes by end user)
• Taylor Integrated Control System (TICS) …see next page for additional info
• 7-in touch screen color display
• TaylorTrak Pro Advanced Fleet Telematics Hardware
• The one-piece flip-down instrument panel is pre-wired to accommodate heavy-dutyaccessories.
• Color and number coded wiring.
• Dual USB charging ports
• Hydrostatic, steer-on-demand power steering with tilt steering column

Electrical

• 24-volt electrical system with 95 amp alternator
• Dual heavy-duty batteries
• Battery disconnect/lock-out switch
• (4) forward facing LED work lights (cab mounted)
• (2) rear facing LED work lights (cab mounted)
• (2) LED work lights (mast mounted)
• Circuit breakers with heavy duty connectors (no automotive type fuses)
• Breaker reset switches
• Key-type anti-restart ignition switch
• Dual electric Trumpet Horns (116 dBA)
• Keyswitch-actuated amber strobe light
• Forward and reverse-actuated warning alarms

Vehicle Information Package

• Operators Guide
• Maintenance and Service documentation including key circuit drawings (SerialNumber Specific Parts Book is available upon request)
• Safety Check Manual and Video
