Standard Features: X-800S & X-900S

• 13-ft ULTRA-VU 2-stage mast (198-in lowered height)
• 120-in Pin-type “C” carriage
• 6-in X 12-in X 96-in pin mounted forks
• Volvo 388-hp Tier-4 final diesel engine
• Donaldson dry-type air cleaner w/safety element & restriction indicator(vertical air intake extension)
• Dana TE-30 5-speed powershift transmission
• Powertrain protection system for engine and transmission
• Kessler D-102 planetary drive axle with wet disc brakes
• Taylor 600 welded steel steer axle (single hydraulic cylinder design with heavy-duty links from the cylinder ram directly to tapered roller bearing mounted spindles)
• 18.00 X 25 – 40PR bias pneumatic drive and steer tires

Chassis

• All-welded steel frame with 4 lifting eyes (lifting eyes not designed for level pick)
• Bolted counterweight
• Replaceable bolt-on steps and handrails
• Lockable Fuel Cap
• Hinged engine hood, side service doors and removable floor panels open to expose drive train for ease of maintenance.

Cab

• Enclosed 2-door steel all-welded DREAM Cab (includes dome light, wide angle mirrors, door hold back latches with trip handles, handrails, black floor mats and is isolation mounted for noise and vibration reduction)
• 32,000 BTU heater and defrost
• Tinted glass with front and rear windshield wipers and washers
• Fully adjustable air ride swivel seat
• Multifunction Joystick mounted on adjustable arm rest (integrated directional shift control)
• Operator Restraint System (Orange, anti-cinch seat belt with starting sequence neutral lock)
• Operator Presence System with timed idle and neutral shutdown(5 minute default, password adjustable from 1-120 minutes by end user)
• Taylor Integrated Control System (TICS) …see next page for additional info
• 7-in touch screen color display
• TaylorTrak Pro Advanced Fleet Telematics hardware
• The one-piece flip-down instrument panel is pre-wired to accommodate heavy-duty accessories.
• All wiring is color and number coded.
• Dual USB charging ports
• Hydrostatic, steer-on-demand power steering with tilt steering column

Electrical

• 24-volt electrical system with 110 amp alternator
• Dual heavy-duty batteries
• Battery disconnect/lock-out switch
• (4) forward facing LED work lights (cab mounted)
• (2) rear facing LED work lights (cab mounted)
• (2) LED work lights (mast mounted)
• Circuit breakers with heavy duty connectors (no automotive type fuses)
• Breaker reset switches
• Key-type anti-restart ignition switch
• Dual trumpet air horns (126 dBA)
• Keyswitch-actuated amber strobe light
• Forward and reverse-actuated warning alarms

Vehicle Information Package

• Operators Guide
• Maintenance and Service documentation including key circuit drawings (Serial Number Specific Parts Book is available upon request)
• Safety Check Manual and Video
