Taylor XH-180Hydro 36

Features

Standard Features:

  • 11-ft. ULTRA-VU 2-Stage Mast (119-in lowered height)
  • 72-in Pin-type "C" Carriage
  • 2.75-in X 7-in X 72-in pin mounted Forks
  • Cummins QSF 3.8L 120Hp Tier-4 Final Diesel Engine
  • Donaldson dry-type air cleaner w/safety element & restriction indicator (vertical air intake extension)
  • RexRoth Hydrostatic Transmission
  • Powertrain Protection System for engine and transmission
  • Kessler D-41 HD planetary Drive Axle with Wet Disc Brakes and Park Brake
  • Taylor 125 welded steel Steer Axle (single hydraulic cylinder design with heavy-duty links from the cylinder ram directly to tapered roller bearing mounted spindles)
  • Solid plate steer angle stop (more contact area than bolt heads which require adjustment)
  • 8.25 X 15 - 18PR bias pneumatic drive and steer tires

Chassis

  • All-welded steel frame with 4 Lifting Eyes (lifting eyes not designed for level pick)
  • Bolted counterweight
  • Replaceable bolt-on steps and handrails
  • Lockable Fuel Cap
  • Sliding engine hood (on rollers), side service doors and removable floor panels open to expose drive train for ease of maintenance.

Cab

  • Isolation mounted open operator base with overhead guard and sky-view window (includes single brake pedal, dome light, wide angle mirrors, handrails and black floor mats).
  • Adjustable Black Vinyl Covered Mechanical Suspension Seat w/Arm Rests (Seat has +/- 15 degree rotation)
  • Multifunction Joystick mounted on adjustable arm rest (11-button command with integrated directional shift control)
  • Operator Restraint System (Orange, anti-cinch seat belt with starting sequence neutral lock)
  • Operator Presence System with timed idle and neutral shutdown(5 minute default, password adjustable from 1-120 minutes by end user)
  • Taylor Integrated Control System (TICS) with 7-in touch screen color display
  • One-piece flip-down instrument panel is pre-wired to accommodate heavy-duty accessories.
  • Color and number coded wiring.
  • Dual USB charging ports
  • Hydrostatic, steer-on-demand power steering with tilt steering column

Electrical

  • 24-volt electrical system with 70 amp alternator
  • Dual heavy-duty batteries
  • Battery disconnect/lock-out switch
  • Circuit breakers with heavy duty connectors (no automotive type fuses)
  • Breaker reset switches
  • Key-type electronics switch with push button start
  • Dual electric trumpet horns (116 dBA)
  • Keyswitch-actuated amber strobe light
  • Forward actuated warning alarm

VIP

  • Operators Guide
  • Maintenance and Service documentation including key circuit drawings (Serial Number Specific Parts Book is available upon request)
  • Safety Check Manual and Video

XH-180Hydro

36" Load Center

Quick Specs
Capacity 18K lbs / 8K kg
Load Center 36 in / 914 mm
Wheelbase 104.0 in / 2641 mm
Transmission RexRoth Hydro Trans.
Mast 11 UV
Carriage C-72
Forks 2.75x7x72 in
Brakes Hydraulic
Volts 24
Tires 8.25 X 15 -18PR
