GTE-70
Electric Lifts



Transmission | TC-32 3-sp. APC |
---|---|
Mast | 125 |
Carriage | |
Forks | 2X5X42 in |
Brakes | Wet Disc |
Volts | 0 |
Tires | 23x10-12F 18x7-8R |
Features
Standard Features: GTE-60, & 70
- 130" Max Fork Height 2-Stage Mast with 85.2-in lowered height (GTE-60)
- 125" Max Fork Height 2-Stage Mast with 85.2-in lowered height (GTE-70)
- 1.75-in X 5-in X 42-in pin mounted Forks (GTE-60)
- 2-in X 5-in X 42-in pin mounted Forks (GTE-70)
- 3-phase AC transistorized drive and pump control
- Enclosed dual 9.0 kW (AC) drive motors (independent control for tight turns)
- 19.1 kW AC hydraulic motor
- Planetary Drive Axle with hydraulically actuated wet disc brakes
- Available in 80V Lithium or 48V Lead Acid
- Fully Boxed Welded Steer Axle (single hydraulic cylinder design with heavy-duty links from the cylinder ram directly to tapered roller bearing mounted spindles)
- Self Activating Parking Brake (SAPB) fully disables the transmission when the parking brake is set
- 23 x 9-10 Solid Pneumatic Drive tires (GTE-60)
- 23 x 10-12 Solid Pneumatic Drive tires (GTE-70)
- 18 x 7-8 PR Solid Pneumatic Steer tires
Cab
- Hydraulic levers conveniently mounted on the hood beside the operator
- Ingress/Egress Handrails
- Rear Handle with Horn Button
- Operator Presence System (traction disable seat switch)
- Hydrostatic Power Steering
- Tilt steering wheel (power steer) with spinner knob
- Dual adjustable convex Rear View Mirrors
- Two pedal brake with inching
- Full-suspension vinyl safety seat with orange seatbelt (w/hip restraints)
- Interactive 5.6 inch" LCD SMART dash (CAN) with On-Board diagnostics
- ZAPI Controllers for advanced control and communication
- Three selectable performance modes and turtle mode
Electrical
- OHG mounted 12 volt LED headlights (including 12 volt converter)
- Rear combination and turn signal lights
- Electric Horn
- Keyswitch-actuated amber strobe light
- Reverse-actuated warning alarms
Vehicle Information Package
- Operator's Guide
- Maintenance and Service Documentation
- Safety Check Manual and Video
Ergonomics
- 11.2" diameter steering wheel with low-effort steer (w/spinner knob)
- Large electronic directional control with no linkage- FWD/REV selected by moving lever up and down
- Large oversized right lever operates turn signals and headlights
- Large welded grab bar handle for solid secure mount
- Deck mounted hydraulic control levers angled at 15 degrees back for precise driver operation
- Self Activating Parking Brake (SAPB) fully disables the transmission when the parking brake is set
Uprights & Carriages
- Nested I-beam upright design
- Canted load rollers
- Silent staging upright cylinders allows no racking between stages
- Negative drop rails provide easy and inexpensive servicing of carriage
- Spherical bushings on both ends of the tilt cylinders
- Carriage features (6) load and side thrust rollers (shimmable, sealed and canted)External side thrust rollers
- Heavy duty roller chain that has 4 x 4 lacing with 1" pitch
- Load back rest pallet protection
- Fully greaseable pivot points
Overhead Guard
- One piece provides strength and durability
- Longitudinal overhead bars for better sight line when load is up
- Low cowl height for greater visibility when load is in lowered position
- Two forward mounted LED work lights with protective guards are standard
- Rear combination lights (brake, tail and back-up) are standard
Available Options
- 80V - 46AH Lithium Battery
- Partial cabs (Top & Front)
- 220V 3 phase lithium battery charger
- Non-marking solid tires
- Side shifters & Fork positioners
- Fingertip controls (mini-levers)
- Accumulators
- Operator Cab with heater
- Weight Scales
- Automatic fork leveling
- Unitrol Directional Control Pedal
- Vision Plus
Industries
Lumber
Distribution
Manufacturing
Food
Textiles
Retail
Features
