GTE-60S
Electric Lifts
24 "
63.4"
6K lbs.
| Transmission | TC-32 3-sp. APC |
|---|---|
| Mast | 130 |
| Carriage | |
| Forks | 1.75X4X42 in |
| Brakes | Wet Disc |
| Volts | 0 |
| Tires | 23x9-10 Front 18x7-8 |
Features
Standard Features: GTE-50 & 60s
- 130" Max Fork Height 2-Stage Mast with 85.2-in lowered height
- 1.75-in X 4-in X 42-in pin mounted Forks (GTE-50)
- 1.75-in X 5-in X 42-in pin mounted Forks (GTE-60s)
- 3-phase AC transistorized drive and pump control
- Enclosed dual 9.0 kW (AC) drive motors (independent control for tight turns)
- 19.1 kW AC hydraulic motor
- Planetary Drive Axle with hydraulically actuated wet disc brakes
- Available in 80V Lithium or 48V Lead Acid
- Fully Boxed Welded Steer Axle (single hydraulic cylinder design with heavy-duty links from the cylinder ram directly to tapered roller bearing mounted spindles)
- Self Activating Parking Brake (SAPB) fully disables the transmission when the parking brake is set
- 23 x 9-10 Solid Pneumatic Drive tires
- 18 x 7-8 PR Solid Pneumatic Steer tires
Cab
- Hydraulic levers conveniently mounted on the hood beside the operator
- Ingress/Egress Handrails
- Rear Handle with Horn Button
- Operator Presence System (traction disable seat switch)
- Hydrostatic Power Steering
- Tilt steering wheel (power steer) with spinner knob
- Dual adjustable convex Rear View Mirrors
- Two pedal brake with inching
- Full-suspension vinyl safety seat with orange seatbelt (w/hip restraints)
- Interactive 5.6 inch LCD SMART dash (CAN) with On-Board diagnostics
- ZAPI Controllers for advanced control and communication
- Three selectable performance modes and turtle mode
Electrical
- OHG mounted 12 volt LED headlights (including 12 volt converter)
- Rear combination and turn signal lights
- Electric Horn
- Keyswitch-actuated amber strobe light
- Reverse-actuated warning alarms
Vehicle Information Package
- Operator's Guide
- Maintenance and Service Documentation
- Safety Check Manual and Video
Chassis
- Single piece all-welded FEA verified steel frame with Heavy Duty fenders
- Integral counterweight
- 40.5" x 28" x 30.5" battery compartment (3435-lbs minimum battery weight)
- Upright/Mast is pin mounted to the chassis (not trunnion mounted to axle)
- Low step height for ease of entry
- Anti-skid steps
- Rubber Elastomeric Axle Dampening Blocks (improves lateral stability)
- Recessed Tow Pin
Steer Axle
- Heavy duty steer axle incorporates integral double steer cylinder
- Single piece steer knuckles supported by tapered roller bearings which provide high durability and low maintenance
- Full hydrostatic operation reduces mechanical links and eliminates kick back
- Mounted on rubber isolator
Ergonomics
- 11.2" diameter steering wheel with low-effort steer (w/spinner knob)
- Large electronic directional control with no linkage - FWD/REV selected by moving lever up and down
- Large oversized right lever operates turn signals and headlights
- Large welded grab bar handle for solid secure mount
- Deck mounted hydraulic control levers angled at 15 degrees back for precise driver operation
- Self Activating Parking Brake (SAPB) fully disables the transmission when the parking brake is set
Uprights & Carriages
- Nested I-beam upright design
- Canted load rollers
- Silent staging upright cylinders allows no racking between stages
- Negative drop rails provide easy and inexpensive servicing of carriage
- Spherical bushings on both ends of the tilt cylinders
- Carriage features (6) load and side thrust rollers (shimmable, sealed and canted)
- External side thrust rollers
- Heavy duty roller chain that has 4 x 4 lacing with 1" pitch
- Load back rest pallet protection
- Fully greaseable pivot points
Overhead Guard
- One piece provides strength and durability
- Longitudinal overhead bars for better sight line when load is up
- Low cowl height for greater visibility when load is in lowered position
- Two forward mounted LED work lights with protective guards are standard
- Rear combination lights (brake, tail and back-up) are standard
Available Options
- 80V - 46AH Lithium Battery
- Partial cabs (Top & Front)
- 220V 3 phase lithium battery charger
- Non-marking solid tires
- Side shifters & Fork positioners
- Fingertip controls (mini-levers)
- Accumulators
- Operator Cab with heater
- Weight Scales
- Automatic fork leveling
- Unitrol Directional Control Pedal
- Vision Plus
Industries
Lumber
Distribution
Manufacturing
Food
Textiles
Retail
