ZLC-995
Electric Lifts
HIGH
236.0"
90K lbs.
| Transmission | |
|---|---|
| Mast | 42' UV |
| Spreader | 20-40 ISO |
| Brakes | Regenerative |
| Tires | 18.00 X 25 - 40PR bias pneumatic drive and steer tires |
Features
Standard Features
- 51' 6" ULTRA-VIEW Telescopic Mast for stacking 6-High (9' 6" Loaded)
- 20-40 ISO Container Handling Attachment, Chain Suspended, with reach, slew, side shift, guide arms and mechanical pile slope
- Accumulator in Lift Circuit
- 650V All-electric battery power drivetrain. Two-full shift run time (under normal work cycles)
- 5 Hour Charge Time (with 180kW charger)
- Dana Dual Hub Drive E-Axle
- Taylor 600 welded steel steer axle with stud protectors (single hydraulic cylinder design with heavy-duty links from the cylinder ram directly to tapered roller bearing mounted spindles)
- 18.00 X 25 - 40PR bias pneumatic drive and steer tires
Chassis
- All-welded steel frame
- Replaceable bolt-on steps and handrails
- Deck plates expose drive train and hydraulics for ease of maintenance.
Cab
- Enclosed, elevated operator, 2-door all-welded steel center mount cab (includes dome light, wide angle mirrors, door hold back latches with trip handles, handrails, black floor mats and is isolation mounted for noise and vibration reduction)
- Operator cab heater and interior circulation fan
- Tinted glass with front and rear windshield wipers and front windshield washer
- Fully adjustable air ride swivel seat with 35 deg. of rotation (15-20 deg. left-right)
- Multifunction joystick mounted on adjustable arm rest
- Roll shift directional control (column mounted)
- Operator Restraint System (Orange, anti-cinch seat belt with starting sequence neutral lock)
- Operator Presence System with timed idle and neutral shutdown (5 minute default, password adjustable from 1-120 minutes by end user)
- Taylor Integrated Control System (TICS)
- 7-in touch screen color display
- The one-piece flip-down instrument panel is pre-wired to accommodate heavy-duty accessories.
- All wiring is color and number coded.
- Dual USB charging ports
- Hydrostatic, steer-on-demand power steering with tilt steering column
Electrical (Low Voltage)
- 24-volt low voltage electrical system. Dual heavy-duty batteries
- 2 Sets of Amber/Green/Red Twistlock operation signal lights (mounted in cab and on container attachment)
- (4) forward facing LED work lights (cab mounted)
- (2) rear facing LED work lights ("A" pillar mounted)
- (2) LED work lights (mast mounted)
- (2) LED work lights (twistlock mounted)
- (2) LED step lights
- 24V Low Voltage System with heavy duty connectors
- Breaker reset switches
- Air Horn with 2-gal air tank (126 dBA)
- Key switch-actuated amber strobe light
- Forward and reverse-actuated warning alarms
Vehicle Information Package
- Operators Guide
- Maintenance and Service documentation including key circuit drawings (Serial Number Specific Parts Book is available upon request)
- Safety Check Manual and Video
Industries
Lumber
Distribution
Manufacturing
Food
Textiles
Retail
Features
Standard Features
- 51' 6" ULTRA-VIEW Telescopic Mast for stacking 6-High (9' 6" Loaded)
- 20-40 ISO Container Handling Attachment, Chain Suspended, with reach, slew, side shift, guide arms and mechanical pile slope
- Accumulator in Lift Circuit
- 650V All-electric battery power drivetrain. Two-full shift run time (under normal work cycles)
- 5 Hour Charge Time (with 180kW charger)
- Dana Dual Hub Drive E-Axle
- Taylor 600 welded steel steer axle with stud protectors (single hydraulic cylinder design with heavy-duty links from the cylinder ram directly to tapered roller bearing mounted spindles)
- 18.00 X 25 - 40PR bias pneumatic drive and steer tires
Chassis
- All-welded steel frame
- Replaceable bolt-on steps and handrails
- Deck plates expose drive train and hydraulics for ease of maintenance.
Cab
- Enclosed, elevated operator, 2-door all-welded steel center mount cab (includes dome light, wide angle mirrors, door hold back latches with trip handles, handrails, black floor mats and is isolation mounted for noise and vibration reduction)
- Operator cab heater and interior circulation fan
- Tinted glass with front and rear windshield wipers and front windshield washer
- Fully adjustable air ride swivel seat with 35 deg. of rotation (15-20 deg. left-right)
- Multifunction joystick mounted on adjustable arm rest
- Roll shift directional control (column mounted)
- Operator Restraint System (Orange, anti-cinch seat belt with starting sequence neutral lock)
- Operator Presence System with timed idle and neutral shutdown (5 minute default, password adjustable from 1-120 minutes by end user)
- Taylor Integrated Control System (TICS)
- 7-in touch screen color display
- The one-piece flip-down instrument panel is pre-wired to accommodate heavy-duty accessories.
- All wiring is color and number coded.
- Dual USB charging ports
- Hydrostatic, steer-on-demand power steering with tilt steering column
Electrical (Low Voltage)
- 24-volt low voltage electrical system. Dual heavy-duty batteries
- 2 Sets of Amber/Green/Red Twistlock operation signal lights (mounted in cab and on container attachment)
- (4) forward facing LED work lights (cab mounted)
- (2) rear facing LED work lights ("A" pillar mounted)
- (2) LED work lights (mast mounted)
- (2) LED work lights (twistlock mounted)
- (2) LED step lights
- 24V Low Voltage System with heavy duty connectors
- Breaker reset switches
- Air Horn with 2-gal air tank (126 dBA)
- Key switch-actuated amber strobe light
- Forward and reverse-actuated warning alarms
Vehicle Information Package
- Operators Guide
- Maintenance and Service documentation including key circuit drawings (Serial Number Specific Parts Book is available upon request)
- Safety Check Manual and Video
