Features
Standard Features: GTE-80, 90, & 100
- 118" Max Fork Height 2-Stage Mast with 88-in lowered height
- 2-in X 5-in X 42-in pin mounted Forks (GTE-80)
- 2-in X 6-in X 42-in pin mounted Forks (GTE-90,100)
- 3-phase AC transistorized drive and pump control
- Enclosed dual 11.3 kW (AC) drive motors (independent control for tight turns)
- 26 kW AC hydraulic motor
- Planetary Drive Axle with hydraulically actuated wet disc brakes
- Available in 80V Lithium or Lead Acid
- Fully Boxed Welded Steer Axle (single hydraulic cylinder design with heavy-duty links from the cylinder ram directly to tapered roller bearing mounted spindles)
- Foot activated parking brake with traction interrupt
- 250 - 15 Solid Pneumatic Drive tires (GTE-80)
- 28 x 12.5 - 15 Solid Pneumatic Drive tires (GTE90,100)
- 21 x 8 - 9 PR Solid Pneumatic Steer tires
Chassis
- Single piece all-welded FEA verified steel frame with Heavy Duty fenders
- Integral counterweight
- 40.5"x 33.6" x 30.8" battery compartment (4,562-lbs minimum battery weight)
- Upright/Mast is pin mounted to the chassis (not trunnion mounted to axle)
- Low step height for ease of entry
- Anti-skid steps
- Rubber Elastomeric Axle Dampening Blocks (improves lateral stability)
- Recessed Tow Pin
Cab
- Hydraulic levers conveniently mounted on the hood beside the operator
- Ingress/Egress Handrails
- Rear Handle with Horn Button
- Operator Presence System (traction disable seat switch)
- Hydrostatic Power Steering
- Tilt steering wheel (power steer) with spinner knob
- Dual adjustable convex Rear View Mirrors
- Full-suspension vinyl safety seat with orange seatbelt (w/hip restraints)
- Programable color LCD display
- ZAPI Controllers for advanced control and communication
Steer Axle
- Heavy duty steer axle incorporates integral double steer cylinder
- Single piece steer knuckles supported by tapered roller bearings which provide high durability and low maintenance
- Full hydrostatic operation reduces mechanical links and eliminates kick back
- Mounted on rubber isolator
Electrical
- OHG mounted 12 volt LED headlights (including 12 volt converter)
- Rear combination and turn signal lights
- Electric Horn
- Keyswitch-actuated amber strobe light
- Reverse-actuated warning alarms
Vehicle Information Package
- Operator's Guide
- Maintenance and Service Documentation
- Safety Check Manual and Video
GTE-80GT-Series |
|||
|---|---|---|---|
| Quick Specs | |||
| Capacity | 8K lbs / 4K kg | ||
| Load Center | 24 in / 610 mm | ||
| Wheelbase | 78.7 in / 1998 mm | ||
| Transmission | TC-32 3-sp. APC | ||
| Mast | 118" Max Fork Height 2-Stage | ||
| Carriage | 2-in X 5-in X 42-in pin mounted Forks | ||
| Forks | 2X5X42 in | ||
| Brakes | Wet Disc | ||
| Volts | |||
| Tires | 250-15 F 21x8-9 R | ||
