Taylor ZEC-207/8 Empty Container Handler

Features

Standard Features

  • 63' ULTRA-VIEW Teloscopic Mast for stacking 6-High (9' 6" Empty) & 7-High (8' 6" Empty)
  • Side Pick 20-40 ISO Container Handling Attachment, Integrated into the Side Shift Carriage(24" each direction). Features guide arms, mechanical pile slope & twistlock safety interlock system.
  • Permanent Magnet Synchronous Motor
  • 90+/- minutes charging time with standard battery configuration
  • 180+/- minutes charging time with extended range battery configuration
  • High voltage electrical system (660 volt)
  • Nickel-Manganese-Cobalt Battery Technology
  • Kessler E-axle (144 P453)
  • Energy Recovery Technology (through regenerative braking)
  • Taylor 310 welded steel steer axle with stud protectors (single hydraulic cylinder design with heavy-duty links from the cylinder ram directly to tapered roller bearing mounted spindles)
  • 14.00 X 24 - 20PR bias pneumatic drive and steer tires

Chassis

  • All-welded steel frame with 4 Lifting Eyes (lifting eyes not designed for level pick)
  • Bolted counterweight
  • Replaceable bolt-on steps and handrails
  • Lockable Fuel Cap
  • Removable deck plates open to expose drive train for ease of maintenance.
  • Cab

    • Enclosed, elevated operator, 2-door all-welded steel center mount cab (includes dome light, wide angle mirrors, door hold back latches with trip handles, handrails, black floor mats and is isolation mounted for noise and vibration reduction)
    • Operator cab heater and interior circulation fan
    • Tinted glass with front and rear windshield wipers and front windshield washer
    • Fully adjustable air ride swivel seat with 35 deg. of rotation (15-20 deg. left-right)
    • Multifunction joystick mounted on adjustable arm rest
    • Roll shift directional control (column mounted)
    • Operator Restraint System (Orange, anti-cinch seat belt with starting sequence neutral lock)
    • Operator Presence System with timed idle and neutral shutdown (5 minute default, password adjustable from 1-120 minutes by end user)
    • Taylor Integrated Control System (TICS)
    • 7-in touch screen color display
    • The one-piece flip-down instrument panel is pre-wired to accommodate heavy-duty accessories.
    • All wiring is color and number coded.
    • Dual USB charging ports
    • Hydrostatic, steer-on-demand power steering with tilt steering column

    Electrical (Low Voltage)

    • 24-volt electrical system with 95 amp alternator
    • Dual heavy-duty batteries
    • Battery disconnect/lock-out switch
    • 2 Sets of Amber/Green/Red Twistlock operation signal lights (mounted in cab and on container attachment)
    • (4) forward facing LED work lights (cab mounted)
    • (2) rear facing LED work lights (cab mounted)
    • (2) LED work lights (mast mounted)
    • (2) LED work lights (twistlock mounted)
    • (2) LED step lights
    • Circuit breakers with heavy duty connectors (no automotive type fuses)
    • Breaker reset switches
    • Key-type anti-restart ignition switch
    • Electric trumpet horn
    • Keyswitch-actuated amber strobe light
    • Forward and reverse-actuated warning alarms

    Vehicle Information Package

    • Operators Guide
    • Maintenance and Service documentation including key circuit drawings (Serial Number Specific Parts Book is available upon request)
    • Safety Check Manual and Video

    ZEC-207/8

    Empty Container Handler

    Quick Specs
    Capacity 20K lbs / 9K kg
    Load Center 103 in / 2616 mm
    Wheelbase 180.0 in / 4572 mm
    Transmission
    Mast 63' UV
    Carriage 20-40 ISO
    Forks in
    Brakes Regenerative
    Volts
    Tires 14 X 24 - 40PR
