Taylor XC-200SL XC-Series

Features

Basic Truck Includes:

  • GM 5.7L-125HP LPG Engine (LPG Tanks Not Included)
  • Remote mounted engine oil filter
  • Dry type Air Cleaner with safety Element and Restriction Indicator
  • Muffler in frame - (LPG engine only)
  • Heavy duty battery
  • 12 Volt electrical system; 105 ampere alternator & Circuit breakers
  • Anti restart ignition system
  • Electric horn 118 DBA
  • Key switch actuated Amber Strobe Lights
  • Reverse actuated Back up alarm
  • Forward actuated forward alarm
  • Electronic Canbus engine (only) diagnostics display
  • Work lights, 2 front and 1 rear
  • Stop, tail lights, turn signals, and reverse lights
  • Powershift Transmission- 3 speed w/ inching, Modulated, & Electric Shift Control
  • Air/Oil Cooling with Automatic Power Shift Control
  • Electric joystick controller for hydraulic controls, right arm rest mounted
  • Bolted planetary drive Axle
  • Oil cooled wet disc brakes, hydraulic actuated with cooler for brake oil and hydraulic oil and accumulators
  • Auxiliary Drive Line Mounted Parking Brake
  • Taylor heavy duty steer axle
  • Hydrostatic power steering
  • Tire: Drive 28" x 12" x 22" black XL Poly Non Marking
  • Tire: Steer 22" x 8" x 16" black XL Poly Non Marking
  • All welded chassis, 56" wide
  • 5# Fire Extinguisher
  • 88-in. Lowered Height Operator overhead guard with overhead opening
  • Tilt Steering
  • Hinged down T-shaped dash
  • Operator fan
  • Two Panoramic Rear View Mirrors
  • Cup Holder
  • Vinyl, air suspension operators seat with orange seat belt and OPS switch, seat has partial rotation 16° left / 24° right
  • 2 Section hydraulic control valve
  • Steering Load sense hydraulics
  • Hydraulic accumulator in lift circuit
  • 2-Stage Telescopic Mast (88-in. Overall Height Lowered)
  • Mast has Two Lift Eyes
  • 53" Wide pin type carriage
  • 2.5" x 7" x 48" pin type forks

XC-200SL

XC-Series

Quick Specs
Capacity 20K lbs / 9K kg
Load Center 24 in / 610 mm
Wheelbase 80.0 in / 2032 mm
Transmission TC-20 3-sp. APC
Mast 7'
Carriage 53
Forks 2.5x7x48 in
Brakes Hydraulic
Volts 12
Tires Drive: 28 x 12 x 22 Poly; Steer: 22 x 8 x 16 Poly
