Taylor XRS-9972H3 Reach Stacker

Features

Standard Features: XRS-9972 H3

  • Telescopic 3-Hook Boom with Side Shift
  • Accumulator in Lift Circuit
  • Volvo 12.8L TAD1371VE 388-HP Tier 4-Final Diesel (Turbocharged)
  • Fuel/Water separator
  • Donaldson dry-type air cleaner w/safety element & restriction indicator
  • Dana TE-30 5-speed powershift transmission
  • Powertrain protection system for engine and transmission
  • Kessler D-102W HD planetary drive axle with wet disc brakes
  • Taylor 800 welded steel steer axle with stud protectors (single hydraulic cylinder design with heavy-duty links from the cylinder ram directly to tapered roller bearing mounted spindles)
  • Drive and Steer Tires: 18.00 x 25 - 40 PR E4 Smooth Tread

Chassis

  • All-welded steel frame with 4 lifting eyes (lifting eyes not designed for level pick)
  • Bolted counterweight
  • Replaceable bolt-on steps and handrails
  • Lockable Fuel Cap
  • Removable deck plates open to expose drive train for ease of maintenance

Cab

  • Climate Controlled sliding (hydraulic/electric) all-welded steel center mount cab (includes right hand and left hand access doors,with rear exit window and dome light)
  • 66,000 BTU total heating with front and rear defrosting, cab pressurizer and fresh air intake
  • 40,000 BTU air conditioning and two circulation fans
  • Exterior Cab Positioning Switch allows the cab to be moved while the machine is powered down
  • Tinted glass with front, rear, and top windshield wipers
  • Front and Top windshield washer
  • Fully adjustable air ride swivel seat with 35░ of rotation (15░/20░ left-right)
  • Multifunction joystick, with integrated directional shift control, mounted on adjustable arm rest
  • Operator Restraint System (Orange, anti-cinch seat belt with starting sequence neutral lock)
  • Operator Presence System with timed idle and neutral shutdown (5 minute default, password adjustable from 1-120 minutes by end user)
  • Taylor Integrated Control System (TICS) ůsee next page for additional info
  • TaylorTrak Pro - Advanced Fleet Telematics Hardware
  • 7-in touch screen color display
  • Rear visibility aid camera system
  • The 2-piece flip-down instrument panel is pre-wired to accommodate heavy-duty accessories.
  • All wiring is color and number coded.
  • Dual USB charging ports
  • Hydrostatic, steer-on-demand power steering with tilt steering column

Electrical

  • 24-volt electrical system with 110 amp alternator
  • Dual heavy-duty batteries
  • Dual Battery disconnect/lock-out switch
  • (4) Chassis mounted LED work lights
  • (4) Boom mounted LED work lightss
  • (2) LED step lights
  • Stop-Tail-Turn Lights
  • Circuit breakers with heavy duty connectors (no automotive type fuses)
  • Breaker reset switches
  • Keyswitch-actuated push button start
  • Air Horn with 2-gal air tank (126 dBA)
  • Keyswitch-actuated amber strobe light
  • Forward and reverse-actuated warning alarms

Vehicle Information Package

  • Operators Guide
  • Maintenance and Service documentation including key circuit drawings (Serial Number Specific Parts Book is available upon request)
  • Safety Check Manual and Video

XRS-9972H3

Reach Stacker

Quick Specs
Capacity 99K lbs / 45K kg
Load Center Vary in / 0 mm
Wheelbase 258.0 in / 6553 mm
Transmission TE-30 5-sp. Powershift
Mast 5-Hi Boom
Carriage 3 Hook Attachment
Forks in
Brakes Hydraulic
Volts 24
Tires 18.00 x 25 - 40PR
